"How To" Guide to Locate and Order a Hoppe Multi-Point Lock Replacement. Follow the steps below, and gather all the information and measurements needed to find your Hoppe Lock components."
1. Measure Your Existing Lock, Write Down the Details.
Step #1 Measure Your Backset.
Step #2 Measure Your "PZ"
Step #3 Measure Your Door Panel Thickness.
Step #4 Measure Your Deadbolt Throw
2. What Type of Door Lock Do You Need? “2 Point In-active Lock”, “3 Point Lock”, “3 Point Edge Only Lock Points” or “5 Point Lock”?
(A) - 2 Point In-Active Door Lock
Locks wih Top and bottom Shootbolts Only. LOCKS INTO THE FRAME HEADER & SILL.
(B) - Single Point Active Door Lock
Locks At Deadbolt Only.
(C) - 3 Point Active Door Lock
Locks with Deadbolt and Top & Bottom Shootbolts. NO OTHER EDGE LOCKING POINTS.
(D) - 3 Point "Edge Locking"
Locks on side Edge of the Door Panel Only. NO TOP OR BOTTOM SHOOTBOLTS.
(E) - 5 Point Lock
Locks with Deadbolt and Top & Bottom Shootbolts & Side Edge Locking Points.
3. Measure Your Handle Height & Edge Locking Points, If you have them.
What is the Measurement to the first Edge Locking Point from the bottom of the door panel Up to the center of the Lower Edge Locking Point?
Measure the Handle Height from the bottom of the door panel to the Handle Height Line?
What is the Measurement to the first Edge Locking Point from the bottom of the door panel Up to the center of the Upper Edge Locking Point?
4. What Type of "Edge Locking Points" Do You Have, If Any?
Tongue
Roller Pin
Swinghook
RoundBolt
None
5. Handle / Lock Configuration
“A” Handle ABOVE European Profile Key Cylinder- (HLS-9000 Series) – Most Common
“B” Handle BELOW American Key Cylinder – (HLS-7 Series) – Special Order
Handle Above = HLS-9000 Series
Handle Below = HLS7 Series
Key Above = American Cylinder
Key Below = European Profile Cylinder
With the details you have gathered, you should be able to locate the lock that you are seeking. Scroll down to the catagory that fits the details you have collected. Use the details you have collected to navigate your way.
Scroll Down to your Lock Category and Select
Scroll Down To Locate Your Lock Type
Hoppe Active Panel Locks - Manual Activation
Hoppe Replacement Gearboxes - For HLS-9000 ONLY
Gearboxes to repair Hoppe HLS-9000 multipoint door Locks that currently have a small mis-handling device wedge between the latch and the deadbolt.
35mm Gearbox only
HLS-9000 Gearbox
35-92-25
SPECIAL ORDER
35-92-25
SPECIAL ORDER
Hoppe 35-92-25
Click below to go to the product page. Then you can "Buy Now" then proceed to checkout
Go to Product Page
Hoppe Gearbox only, 35mm ( 1 3/8″ ) Backset with a 1″ deadbolt. Replaces all Hoppe HS-9000 multipoint gear boxes on existing locks with a ” Mis-Handling /Dead Latch” feature just above the deadbolt
45MM Gearbox only
HLS-9000 Gearbox
45-92-25
USUALLY IN STOCK
45-92-25
USUALLY IN STOCK
Hoppe 45-92-25
Click below to go to the product page. Then you can "Buy Now" then proceed to checkout
Go to Product Page
Hoppe Gearbox only, 45mm ( 1 3/4″ ) Backset with a 1″ deadbolt. Replaces all Hoppe HS-9000 multipoint gear boxes on existing locks with a ” Mis-Handling /Dead Latch” feature just above the deadbolt
60MM Gearbox only
HLS-9000 Gearbox
60-92-25
SPECIAL ORDER
60-92-25
SPECIAL ORDER
Hoppe 60-92-25
Click below to go to the product page. Then you can "Buy Now" then proceed to checkout
Go to Product Page
Hoppe Gearbox only, 60mm ( 2 3/8″ ) Backset with a 1″ deadbolt. Replaces all Hoppe HS-9000 multipoint gear boxes on existing locks with a ” Mis-Handling /Dead Latch” feature just above the deadbolt
70MM Gearbox only
HLS-9000 Gearbox
70-92-25
SPECIAL ORDER
70-92-25
SPECIAL ORDER
Hoppe 45-92-25
Click below to go to the product page. Then you can "Buy Now" then proceed to checkout
Go to Product Page
Hoppe Gearbox only, 70mm ( 2 3/4″ ) Backset with a 1″ deadbolt. Replaces all Hoppe HS-9000 multipoint gear boxes on existing locks with a ” Mis-Handling /Dead Latch” feature just above the deadbolt.
Hoppe Single Point Locks -HLS-9000
Hoppe Single point locks. Locks only at the deadbolt. . Does not require lifting of the handle to lock, NOT A REPLACEMENT FOR MULTIPOINT GEARBOX.
Single Point - Locks At Deadbolt Only
Single Point
35 / 14
1 3/8" Backset with 1/2" Deadbolt Throw
Single Point
35 / 25
1 3/8" Backset with 1" Deadbolt Throw
Single Point
45 / 14
1 3/4" Backset with 1/2" Deadbolt Throw
Single Point
45 / 25
1 3/4" Backset with 1" Deadbolt Throw
Single Point
60 / 25
2 3/8" Backset with 1" Deadbolt Throw
Single Point
70 / 25
2 3/4" Backset with 1" Deadbolt Throw
3 Point Multipoint Locks - Manual Activation
By Edge Locking Point Types
Locks at the Deadbolt and two other locking points only.
3 Point - Edge Locking Points Only
Hoppe Tounge Lock
Hoppe Multi-point Locks with tongue locking point below the deadbolt.
Hoppe Roller Pin
Hoppe Multi-point Locks with roller pin locking point below the deadbolt.
Hoppe Swing Hook Lock
Swing Hook Lock That Locks On the edge only. No Bottom shoot bolt.
Hoppe Swing Hook Lock
Swing hook lock that locks on the door edge only. 3 point multipoint lock
Go To Catalog Page
Hoppe Roundbolt
Hoppe Multi-point Locks with roundbolt locking point below the deadbolt.
3 Point - Deadbolt & Top / Bottom Shootbolts Only
Hoppe 3 Point Lock
Multipoint lock that locks at top and bottom as well as the deadbolt
Variable 3-Point lock
Variable Handle Height for 3 point locks that have a handle height other than 36"
Hoppe 3 Point Lock
Variable 3 point lock for locks with a handle height other than 36:.
Go To Catalog Page
5 Point Locks - Manual Activation
By Edge Locking Type
Locks at The Deadbolt, (2) Edge locking points and(2) Shootbolts.
5 Point Locks- (1) Deadbolt, (2) Edge Locking Points, (2) Shootbolts
Tongues With Shootbolts
Hoppe 5 Point Tongue with Shootbolt
Hoppe Tongue Lock With Bottom Shootbolt
Hoppe Multi-point Locks with tongue locking point below the deadbolt.
Go To Catalog Page
Roller Pins With Shootbolts
Hoppe 5 Point Roller Pin Lock with Shootbolt
Hoppe Roller Pin With Shootbolt
Hoppe Multi-point Locks with roller pin locking point below the deadbolt.
Go To Catalog Page
Swinghooks
With
Shootbolts
Hoppe 5 Point Swing Hook With Shootbolt
Hoppe Swing Hook Lock With Bottom Shootbolt
Very Secure 5 point locking system with swing hooks and shootbolts
Go To Catalog Page
Roundbolts
with
Shootbolt
5 Point Roundbolt With Shootbolt
Hoppe Roundbolt Lock with Bottom Shootbolt
Hoppe Roundbolt Lock With Bottom Shhotbolt. 5 point Locking system
Go To Catalog Page
Hoppe Active Panel Locks - Automatic Activation
Automatic 3 Point Locks - Edge Locking Points Only
35mm & 45mm Backsets, Not Available With Shootbolts
Automatic 3 Point - Deadbolt & Edge Locking Points Only
Automatic Tongue Locks
Trigger activated tongue engagement
Automatic Tongue multipoint locks, No Shootbolt
Locks automatically when you close the door. Tongues extend by trigger rellease
Go to Catalog Page
This type of automatic tongue lock activates it’s side edge tongue locking point when the door is closed. Just turn the thumb turn to lock the door. Lever handle does not have to be lifted to activate locking points, Only available in 35mm and 45mm backsets. Not available with shootbolts.
Automatic Tongue Top Extensions
Tongue Top Extensions
Automatic Tongue multipoint locks, No Shootbolt
Locks automatically when you close the door. Tongues extend by trigger rellease
Go to Catalog Page
Top extensions for automatic tongue locks, Trimmable for a variety of door heights.
Automatic Roller Pin Locks
Trigger activated roller pin engagement
This type of automatic roller pin lock activates it’s side edge roller pin locking point when the door is closed. Just turn the thumb turn to lock the door. Lever handle does not have to be lifted to activate locking points, Only available in 35mm and 45mm bacskets. Not available with shootbolts.
Automatic Roller Pin Top Extensions
Roller Pin Top Extensions
Automatic Roller Pin Top Extensions
Roller Pin Top Extensions for Automatic Locks
Go to Catalog Page
Top extensions for automatic roller pin locks, Trimmable for a variety of door heights.
Inactive 2 Point Door Lock - Manual Activation
Available in 35mm, 45mm, 60mm & 70mm Backsets
36" Handle Height, , Shootbolt only Locking Points
2 Point In-Active Door Lock- Top / Bottom Shootbolts Only
Hoppe In-Active Lock
For Handle Activated 2 Point Inactive locks, 36"HH
Hoppe In-Active Door Lock
For Inactive door lock replacement with 36" Handle Height Double Doors
Go to Catalog Page
For In-active 2 Point Locks with a handle height of exactly 36″ from the bottom the the door panel up to the center of the handle.
Variable In-Active Lock
Handle heights from 34 1/4" to 38 1/8".
Hoppe In-Active Door Lock
For Inactive door lock replacement For Handle Heights, Greater or Less than 36"
Go to Catalog Page
For In-active 2 Point Locks with a handle height between 34 1/14″ to 38 1/8″. This Lock body requires a Lower Extension and cover plate. Add a Top extension for a complete locking system.
HLS-5000 Sliding Door - 2 Hook Lock
HLS-5000 Sliding Door
30mm Backset, 16mm Faceplate
16mm (5/8″ )Wide Faceplate and 30mm (1 3/16″) Backset
HLS-5000 Sliding Door
35mm Backset, 16mm Faceplate
16mm (5/8″ )Wide Faceplate and 35mm (1 3/8″) Backset
HLS-5000 Sliding Door
30mm Back set, 20mm Faceplate
20mm (3/4″ )Wide Faceplate and 30mm (1 3/16″) Backset
HLS-5000 Sliding Door
35mm Back set, 20mm Faceplate
20mm (3/4″ )Wide Faceplate and 35mm (1 3/8″) Backset
Locks Specific To Door Manufacturer
Locks Known To Be Used Exclusively By Door Manufacturer
Caradco 4101341 Actiive Lock
Replacement Lock for Caradco 4101341 Active Door
Caradco Active Door Lock
Direct Lock Replacement for Caradco and Jeld-Wen Door Locks
Go To Product Page
This lock is for a Caradco 4101341 active door. Also works on Jeld-wen active French doors.
Caradco 4101341 Inactive Lock
Replacement Lock for Caradco 4101341 Active Door
This lock is for the in-active panel on a double French door.
PGT 750 Series Concealed Door Lock
Concealed lock that operates threaded rods to lock.
This lock is a concealed lock that fits inside of a PGT 750 series French door. It has a top and bottom coupler for 5/16″ threaded rods. Lock is activated by lifting the lever handle which engages the top and bottom rods into the frame header and sill. Lock has a 2 3/8″ Backset, Handle below dead bolt.
Marvin Door Locks (Formally SIW Windows and Doors, Fullex Replacement locks for Ultimate Doors of Palm Beach, Weather Shield Legacy Series Door Locks and More.....
SIW / Marvin Door Lock
Door lock for French doors by SIW (Now Marvin)
SIW French Door Replacement multipoint locks
Ultimate Door of Palm Beach
Fullex Multipoint Lock Replacement
Ultimate Door of Palm Beach French Door Replacement multipoint locks
Weather Shield
Legacy series locks
3 Point Concealed multipoint lock
Weather Shield Legacy series French door lock replacement
Common Signs That Indicate Your Multi-Point Lock Will Fail Soon.
When was the last time you Lubricated Your Multipoint Door Locks to increase their operation and lifespan?
- Lock Get Jammed Easily
- Handle Sags Downward
- Broken Return Springs
- Stripped Spindles
- Ratcheting Lock Engagement
- Broken Lock Keepers
- Deadbolt Does Not Extend
- Crunchy Noise When Locking
